Forklift Starters and Alternators - A starter motors today is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid installed on it. Once current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion with the starter ring gear that is seen on the flywheel of the engine.
As soon as the starter motor begins to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid has a key operated switch which opens the spring assembly to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this way through the pinion to the flywheel ring gear. The pinion remains engaged, for example for the reason that the driver fails to release the key when the engine starts or if the solenoid remains engaged because there is a short. This actually causes the pinion to spin independently of its driveshaft.
The actions mentioned above would stop the engine from driving the starter. This important step stops the starter from spinning really fast that it could fly apart. Unless adjustments were made, the sprag clutch arrangement will prevent utilizing the starter as a generator if it was employed in the hybrid scheme discussed earlier. Usually a standard starter motor is meant for intermittent utilization that would stop it being utilized as a generator.
The electrical parts are made in order to work for approximately thirty seconds to be able to prevent overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are meant to save weight and cost. This is the reason most owner's instruction manuals meant for automobiles suggest the driver to stop for a minimum of ten seconds right after each 10 or 15 seconds of cranking the engine, when trying to start an engine that does not turn over at once.
The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Prior to the 1960's, a Bendix drive was used. This particular drive system works on a helically cut driveshaft which has a starter drive pinion placed on it. When the starter motor begins spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design which was made and introduced in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism along with a set of flyweights in the body of the drive unit. This was better in view of the fact that the standard Bendix drive used so as to disengage from the ring once the engine fired, even though it did not stay functioning.
As soon as the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, for instance it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be avoided previous to a successful engine start.
